Horn Antennas

The frequency coverage of this series of horn antennas is wide, ranging from 1GHz to 110GHz, which can meet the requirements of different fields for signal transmission and reception in different frequency bands. The gain ranges from 10dBi to 25dBi, which can effectively enhance the signal strength and improve the communication and detection distance and accuracy. The polarization mode is linearly polarized, ensuring the stability and directivity of signal transmissio

In terms of design, this series of products pays attention to details and quality. They are manufactured with high-quality materials and go through strict production processes and quality inspection procedures to ensure that each antenna can meet or exceed industry standards, providing users with reliable signal transmission solutions.

Connector: A variety of standard connector series are adopted, such as WR10, WR15, WR19, WR22, SMA female connector, and N female connector. This facilitates the connection with different devices and ensures the stability of the connection and the matching of electrical performance. Flange: Some models are designed with standard flanges such as UG - 385/U and UG - 383/U, which makes installation and fixation easier and guarantees the stability of the antenna during use.

The main body materials include gold - plated brass and aluminum. The gold - plated brass material has good electrical conductivity and corrosion resistance, which can effectively reduce signal loss and improve the performance of the antenna. The aluminum material has the advantages of light weight and low cost, making it suitable for application scenarios with weight requirements.

This series of horn antennas is a high-performance antenna product specifically designed to meet the application scenarios of various communications, radars, and test & measurement. They possess excellent electrical performance and a reliable mechanical structure, enabling stable operation within their respective corresponding frequency bands

Sku	Connector Series		Frequency	Gain	Polarization
GHA7501100-WR10-25	WR10		75GHz~110GHz	25dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	UG-385/U		Brass Plating Gold	Brass Plating Gold	Wide

Sku	Connector Series		Frequency	Gain	Polarization
GHA500750-WR15-25	WR15		50GHz~75GHz	25dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	UG-385/U		Brass Plating Gold	Brass Plating Gold	Wide

Sku	Connector Series		Frequency	Gain	Polarization
GHA392596-WR19-25	WR19		39.2GHz to 59.6GHz	25dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	UG-383/U		Brass Spray Black Paint	Brass Plating Gold	Wide

Sku	Connector Series		Frequency	Gain	Polarization
GHA329501-WR22-25	WR22		32.9GHz to 50.1GHz	25dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	UG-383/U		Brass Spray Black Paint	Brass Plating Gold	Wide

Sku	Connector Series		Frequency	Gain	Polarization
GHA180260-SMF-20	SMA Female		18GHz to 26GHz	20dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	NA		Aluminum	Brass Plating Gold	Wide

Sku	Connector Series		Frequency	Gain	Polarization
GHA040120-SMF-10	SMA Female		4GHz to 12GHz	10dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	NA		Aluminum	Brass Plating Gold	Wide

Sku	Connector Series		Frequency	Gain	Polarization
GHA060180-SMF-14	SMA Female		6GHz to18GHz	14dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	NA		Aluminum	Brass Plating Gold	Wide

Sku	Connector Series		Frequency	Gain	Polarization
GHA0118A-11	N Female		1GHz to18GHz	11dBi	Linear
Antenna Type	Flange Designation		Body Material	Connector Material	Number of Bands
Horn	NA		Aluminum	Brass Plating Gold	Wide
