RF Adapter

Your Professional RF Adapter Supplier!

Flexi RF Inc. was founded in 2023 in Santa Clara, California - at the heart of Silicon Valley, by a team of experienced RF engineers. We specialize in the design, manufacture, and supply of passive and active RF components. Our product line includes passive components such as antennas, connectors, adapters, cable assemblies, attenuators, and loads; and active components such as amplifiers, switches, and select custom modules.

Why Choose Us

OEM and ODM
We offer both OEM and ODM services with no minimum order quantity. Whether you are developing a next-generation system or require a mature RF module solution, we provide products and technical support that scale with your innovation.

Our Services
Flexi RF offers a one-year warranty on standard products, ensuring that our service remains reliable and efficient.

Real-Time Response
Our cross-border team, spanning China and the United States, can respond to customer needs around the clock, ensuring seamless and efficient service across time zones.

Professional Team
With decades of industry experience and professional R&D as well as manufacturing facilities, our team of experienced engineers possesses strong independent innovation capabilities, enabling us to provide customers with high-quality customized RF solutions.

Specification

Configuration
Connector 1 Type	1.0mm
Connector 1 Impedance	50 Ohms
Connector 1 Polarity	Standard
Connector 2 Type	1.0mm / 1.85mm
Connector 2 Impedance	50 Ohms
Connector 2 Polarity	Standard
Connector Mount Method	None
Adapter Body Style	Straight
Materials Information
Center Contact	CuBe Gold Plated
Outer Contact	Stainless Steel
Body	Stainless Steel
Dielectric	PEI
Environmental Data
Temperature Range	-40℃ to +85℃
2011/65/EU(RoHS)	Compliant

RF Adapter Key Features and Benefits

Durability and Reliability

Most RF adapters are made from high-quality materials such as brass or stainless steel, often with gold-plated contacts to ensure corrosion resistance and long-lasting performance.

Ease of Use

RF adapters are designed to be simple to install and use, making them ideal for both professional engineers and DIY enthusiasts.

Cost-Effectiveness

By enabling different systems and components to work together without the need for entirely new cabling or devices, RF adapters provide a cost-effective solution for a variety of applications.

The Type of RF Adapter

Coaxial Adapter

For connecting Coaxial connectors of the same type, such as SMA to SMA, n to N, etc. .

Inter-Series Adapter

Used to connect different series of coaxial connectors, such as SMA to N, BNC to TNC, etc. .

Panel Mount Adapter

Designed to be mounted on the Panel of a device to provide convenient connectivity.

Attenuating Adapter

In addition to the connection function, it includes attenuators for reducing signal strength.

Conversion Adapter

Connectors for connecting different genders, such as male to female or vice versa.

Right Angle Adapter

Provides a 90-degree bend for use in situations where space is limited.

RF Adapter Grade

There are usually three grades of each type of RF adapter available, providing the right adapter for each type while balancing cost and performance.

Measurement level

● Standard parts for calibration
● Highest performance slotless connection design
● Minimal tolerances
● Air media
● Long life
● High production cost

Instrument Grade

● Used on the output input interface of the instrument and some economical calibrators
● Better performance
● Smaller tolerances
● Supports non-conductive media interfaces
● Long service life

Production Grade

● Used in products
● Low performance
● Large Tolerances
● Supports non-conductive media interfaces
● Limited number of connections
● Low cost

Application of RF Adapter

Communication Field

For wireless communication system, satellite communication and so on.

Testing and measurement

Widely used in RF testing, such as Spectrum Analyzer, Network analyzer, etc.

Military and defense

For military communications systems, radar systems, etc.

Medical Equipment

Plays an important role in the RF connection and transmission of medical equipment.

Aerospace

Communication and radar systems used in the aerospace field.

Automobiles and transportation

Applications in automotive wireless communication systems, vehicle-borne radars, etc. .

Industrial Automation

For Industrial Wireless Communications, sensor networks, etc. .

Installation of RF Adapter

Proper selection and installation of RF adapters requires the following steps:

01/

Determine the two RF interface types that need to be transferred, such as SMA and N type.

02/

Identify the frequency range that needs to be transferred and select the appropriate RF adapter for that frequency range.

03/

Identify the type of signal to be transferred, such as analog or digital, and select the appropriate RF adapter.

04/

Select the appropriate material and connection method, such as solder or threaded connection.

05/

Ensure proper tools and skills are used when making connections to avoid damage to the RF adapter.

06/

Before installation, clean and inspect the connection points to ensure that there are no impurities or damage.

07/

When installing RF adapters, make sure the connection is tight to avoid signal attenuation and interference.

08/

After installation, perform tests to ensure that the performance of the adapter meets the requirements.

Customization Services

To better meet the diverse needs of different industries and customers, we can tailor RF adapter professional solutions to your specific application scenarios and special requirements. For further information or support, please feel free to contact us.

Order Process

Contact Customer Service

Submit Order

Obtain a Quote

Confirm Order

Arrange Payment

Track Order

Receive and Inspect Goods

Packaging and Shipping

Packaging	Plastic bags, paper boxes
Transportation methods	Road transport, rail transport, sea transport, air transport

FAQ

Q: What does an RF adapter do?

A: RF adapters are a device used to connect and convert RF signals of different types or different frequencies. It usually consists of two connectors and a converter, which can convert one type of connector to another type of connector, or convert a signal of one frequency to another frequency.

Q: How does an RF adapter work?

A: RF adapters work by matching the physical connections between different connectors to ensure minimal signal loss and maximum transmission efficiency. They achieve device connections by converting connector types or specifications.

Q: Where we can get products information from?

A: You can go through our website links as below: www.flexirf.com Also you can contact our international marketing team.

Q: Why choose Flexi RF?

A: Flexi RF have a young international team with many years' experience cooperate with more than 30 countries in outdoor camping line.
Flexi RF focus on design and supply innovation, suitable and competitive outdoor camping products.

We're professional rf adapter manufacturers and suppliers in USA, specialized in providing high quality customized service. We warmly welcome you to buy high-grade rf adapter in stock here from our factory.

1 85mm to 2 92mm Precision Adapter 40GHz, SMA Precision Adapter DC to 18GHz, SMA to SSMA Adapter 6 18GHz
